DC12V Car Park Boom Gates , Boom Barrier System Brushless DC Motor For Malaysia

Brand Name : WONSUN

Model Number : DZ-138

Certification : CE/ISO/SGS

Place of Origin : China

MOQ : 1PC

Price : Negotiated

Payment Terms : T/T,Western Union,Money Gram, Trade Assurance,Paypal etc.,

Supply Ability : 1000 Sets/Month

Delivery Time : 3-7 working days after received your payment

Packaging Details : Packed in bubble wrap firstly, and then reinforced with carton for outer packing.

Product Name : Brushless DC Motor Gate Barrier System Automatic Boom Barrier Price For Malaysia

Motor Rated Power : 50W,max 100W

Running Speed : 0.3s/0.6s/0.9s/2s/4s(adjustable)

Rating Voltage : AC90~264V,DC12V

Meterial : 2mm cold-roll steel sheet

Housing Size : 342*312*959mm

Remote Control Distance : ≤100m

Keyword : Automatic boom barrier

Contact Now

Brushless DC Motor Gate Barrier System Automatic Boom Barrier Price For Malaysia


Automatic Boom Barrier Details:

DZ-138 Model Barrier Gate,is designed using innovative technology and manufactured with precision machinery toguaarantee satisfaction in quality and reliability for years to come.Main features are as belows:

  • ​the speed can be adjusted from 0.6sec to 6sec

  • operation time:0.6S/0.9S/2s/4s/6S for option
  • arm direction can be easily changed to "LEFT" or "RIGHT" side
  • encoder limit (more accuracy,no need to adjust it)
  • more than 10 million operation times(> 10 years)

​DC12V Car Park Boom Gates , Boom Barrier System Brushless DC Motor For Malaysia



























Technical Specification



1 Product Name Brushless DC Motor Gate Barrier System Automatic Boom Barrier Price For Malaysia
2 Rated Volatge AC90V~AC264V,DC24V,50/60HZ
3 Speed Time 0.3s,0.6s,0.9s,2s,4s,6s
4 Motor Power 50W,max 100W
5 Boom Length 2meter to 6meter(max)
6 Working Temperature -40℃~85℃
7 Housing Size 342*312*959*2mm(L*W*H*TH)
8 Lifetime >10 million times or 10 years
9 MTTR <0.5hour
10 MTBF >5 million times
11 Protection Grade IP68
12 Remote Controll Distance ≤100 meter
13 Motor Speed 3000 r/min
14 Relative Humidity ≤90%
15 Running Noise <50dB
16 Net Weight 42.6KG
17 Application Parking Lots, Toll Gates, Goods Yards, Railway Crossings,Commercial Premises, Apartment Block Access



Features& Functions:


1. Gate automatically open when power off, no clutch design, no need human intervention.
2.Use Single Compression Balance Spring device, good regulation, no noise,  safe and reliable.
3.A variety of input and output modes can be selected, normally open normally closed are optional.
4. Arm opening angle can be adjusted from 60 to 90 degrees, 10 degrees resolution, suitable for eaves prominent place to install.
5. Closing speed can be adjusted.
6. Barrier gate up &down signal relay switch output.
7. Barrier gate running state: OK signal output indicating that the gate is working properly.
8. Barrier gate operation abnormal alarm signal output.
9. R&G Traffic light relay switch signal output.
10. External loop detector signal anti-smashing interface, infrared sensor signal anti-smashing interface.
11. Count mode interface.
12. Arm Open priority anti-smashing function.
13. Barrier with anti-collision protection function.
14. Delay closed selection function.
15. High-sensitivity arm auto reverse function (intensity can be adjusted).
16. Parking system interface.
17.RS485 or RS232 network communication control up &down interface(no need to install communication module)
18. Anti-collision alarm signal interface.
19. Adjustable speed port (from 0.9s to 10 s)


Company Information:

DC12V Car Park Boom Gates , Boom Barrier System Brushless DC Motor For Malaysia


Packing List:



Title Specification Qty Unit Note
Barrier gate boom   1 Piece
Machine case press board   2 piece For fixing case
Expansion bolt M16X150 4 set For fixing case
Supporting pole   1 piece Optional part
Expansion bolt M8 4 unit For fixing boom
Boom fixed screws M12*70 2 unit
Case Key   2 unit
Balance spring   1 unit For spare usage
Remote controller   2 unit
Machine control   1 unit Optional
Instruction   1 piece





RFQ:

Q: What's the order process?

A: Follow the steps on below to complete your order.
- 1. Inquiry
Provide us detailed information about your requirement, and we'll recommend the suitable products according to your request
-2. Quotation
Official quotation form with all clear specifications according to the order
-3. Invoice
Invoice will be issued once the quotation is confirmed.
-4. Payment
Payment shall be issued once the invoice issued. Full payment is acquired.
-5. Production
Bulk production shall be taking 15-25 working days.
-6. Delivery
by sea, air or courier. Detailed picture of package will be provided upon the service you've chosen. Packaging info will be sent upon confirmation.





Service Items



1 2 year’s free servicing is supplied(not including the arm);

9.2 Lifetime charged servicing is offered;

9.3 Technology servicing is supplied.

The following situations are charged for servicing(or changing):

1) Broken by the wrong installation.

2) Broken by improper voltage.

3) The surfaces of the system destroyed by wrong installation or use.

4) Broken by natural disaster.

5) Overdue.

6) Servicing items out of our promises.
